The Honeywell HD3MDIP is an advanced, high-definition fixed mini-dome camera from the acclaimed equIP® Series of IP-based security products. Engineered for professional indoor surveillance, this camera delivers crisp 720p (Megapixel) images while maintaining minimal bandwidth consumption, making it an ideal choice for new IP installations or cost-effective upgrades to existing analog systems.
Key Features & Performance
- 720p Megapixel Resolution: Provides outstanding image quality (1280 x 720) at a full frame rate of 30 frames per second (fps), offering significantly more detail than standard analog CCTV cameras.
- True Day/Night (D/N): Features a removable IR Cut Filter that automatically switches the camera from vivid color images during the day to clear black-and-white images at night, enhancing low-light performance.
- 3.3–12 mm Vari-focal Auto Iris (VFAI) Lens: Allows the installer to adjust the field of view and focus to perfectly suit the monitoring area’s requirements, offering flexibility during setup.
- Digital Noise Reduction (DNR): Reduces image noise in low-light conditions, resulting in clearer video and significant storage savings without sacrificing essential detail.
- Dual Stream Support: Capable of generating two independent digital video streams simultaneously (using formats like MPEG-4 and MJPEG), allowing for flexible viewing and recording configurations (e.g., high-quality local recording and lower-bandwidth remote viewing).
Network & Installation Advantages
- Power over Ethernet (PoE): Built-in IEEE 802.3af (Class 1) PoE capability allows the camera to be powered directly through the standard network cable, simplifying installation and eliminating the need for a separate power supply and associated wiring.8 (Can also be powered by 24 VAC).
- Tamper and Motion Detection: Includes integrated camera tamper detection (alerts if the camera is blocked or moved) and video motion detection to provide automated security alerts.
- Installer-Friendly Design: Compact, one-piece design with a 3-axis gimbal (Pan 360°, Tilt 180°, Rotation 360°) simplifies aiming and mechanical adjustment.10 It comes ready for both surface mount and recessed ceiling applications.
- Bi-directional Audio Support: Features line-in/line-out connections for two-way audio communication, adding an extra layer of surveillance capability.
Technical Summary
| Parameter | Specification |
| Video Resolution | 720p (1280 x 720) |
| Frame Rate | Up to 30 fps (NTSC) / 25 fps (PAL) |
| Image Sensor | 1/4″ Progressive Scan CMOS |
| Lens | 3.3–12.0 mm Vari-focal Auto Iris (VFAI), F1.6 |
| Day/Night | True Day/Night (TDN) with Removable IR Cut Filter |
| Power | PoE (IEEE 802.3af, Class 1) or 24 VAC |
| Video Compression | MPEG-4, MJPEG |
| Indoor/Outdoor | Indoor |
| Audio | Bi-directional (Line in/out) |
This Honeywell HD3MDIP camera is a professional-grade solution for reliable, high-definition indoor IP video surveillance that optimizes image clarity while controlling network bandwidth.
